cqasm::v1::semantic Namespace Reference

Detailed Description

Namespace for the semantic tree node classes.

Classes
class	Annotated
	Represents a node that carries annotation data. More...
class	AnnotationData
	Represents an annotation. More...
class	Block
	A block of statements. More...
class	BreakStatement
	A break statement. More...
class	Bundle
	A bundle of instructions, to be executed in parallel. More...
class	BundleExt
	A bundle of instructions, to be executed in parallel. More...
class	ContinueStatement
	A continue statement. More...
class	Dumper
	Visitor class that debug-dumps a tree to a stream. More...
class	ErrorModel
	Error model information. More...
class	ForeachLoop
	A foreach loop. More...
class	ForLoop
	A C-style for loop. More...
class	GotoInstruction
	A version 1.2+ goto instruction. More...
class	IfElse
	An if-else chain. More...
class	IfElseBranch
	A single condition + block for use in an if-else chain. More...
class	Instruction
	A regular instruction. More...
class	InstructionBase
	An instruction (a.k.a. More...
class	Mapping
	A mapping. More...
class	Node
	Main class for all nodes. More...
class	Program
	A complete program. More...
class	RecursiveVisitor
	Visitor base class defaulting to DFS pre-order traversal. More...
class	RepeatUntilLoop
	A repeat-until loop. More...
class	SetInstruction
	A version 1.2+ assignment instruction. More...
class	Statement
	A statement. More...
class	Structured
	Any version 1.2+ structured control-flow statement. More...
class	Subcircuit
	A subcircuit. More...
class	Variable
	A variable. More...
class	Version
	The file version identifier. More...
class	Visitor
	Base class for the visitor pattern for the tree. More...
class	VisitorBase
	Internal class for implementing the visitor pattern. More...
class	WhileLoop
	A while loop. More...

Typedefs
using	Base = cqasm::tree::Base
template<class T >
using	Maybe = cqasm::tree::Maybe< T >
template<class T >
using	One = cqasm::tree::One< T >
template<class T >
using	Any = cqasm::tree::Any< T >
template<class T >
using	Many = cqasm::tree::Many< T >
template<class T >
using	OptLink = cqasm::tree::OptLink< T >
template<class T >
using	Link = cqasm::tree::Link< T >

Enumerations
enum	NodeType {   NodeType::AnnotationData, NodeType::Block, NodeType::BreakStatement, NodeType::Bundle,   NodeType::BundleExt, NodeType::ContinueStatement, NodeType::ErrorModel, NodeType::ForLoop,   NodeType::ForeachLoop, NodeType::GotoInstruction, NodeType::IfElse, NodeType::IfElseBranch,   NodeType::Instruction, NodeType::Mapping, NodeType::Program, NodeType::RepeatUntilLoop,   NodeType::SetInstruction, NodeType::Subcircuit, NodeType::Variable, NodeType::Version,   NodeType::WhileLoop }
	Enumeration of all node types. More...

Functions
std::ostream &	operator<< (std::ostream &os, const Node &object)
	Stream << overload for tree nodes (writes debug dump). More...

Typedef Documentation

Base

using cqasm::v1::semantic::Base = typedef cqasm::tree::Base

Definition at line 151 of file cqasm-v1-semantic-gen.hpp.

Maybe

template<class T >

using cqasm::v1::semantic::Maybe = typedef cqasm::tree::Maybe<T>

Definition at line 152 of file cqasm-v1-semantic-gen.hpp.

One

template<class T >

using cqasm::v1::semantic::One = typedef cqasm::tree::One<T>

Definition at line 153 of file cqasm-v1-semantic-gen.hpp.

Any

template<class T >

using cqasm::v1::semantic::Any = typedef cqasm::tree::Any<T>

Definition at line 154 of file cqasm-v1-semantic-gen.hpp.

Many

template<class T >

using cqasm::v1::semantic::Many = typedef cqasm::tree::Many<T>

Definition at line 155 of file cqasm-v1-semantic-gen.hpp.

OptLink

template<class T >

using cqasm::v1::semantic::OptLink = typedef cqasm::tree::OptLink<T>

Definition at line 156 of file cqasm-v1-semantic-gen.hpp.

Link

template<class T >

using cqasm::v1::semantic::Link = typedef cqasm::tree::Link<T>

Definition at line 157 of file cqasm-v1-semantic-gen.hpp.

Enumeration Type Documentation

NodeType

enum cqasm::v1::semantic::NodeType

strong

Enumeration of all node types.

Enumerator
AnnotationData
Block
BreakStatement
Bundle
BundleExt
ContinueStatement
ErrorModel
ForLoop
ForeachLoop
GotoInstruction
IfElse
IfElseBranch
Instruction
Mapping
Program
RepeatUntilLoop
SetInstruction
Subcircuit
Variable
Version
WhileLoop

Definition at line 195 of file cqasm-v1-semantic-gen.hpp.

Function Documentation

operator<<()

std::ostream & cqasm::v1::semantic::operator<<	(	std::ostream &	os,
		const Node &	object
	)

Stream << overload for tree nodes (writes debug dump).

Definition at line 5748 of file cqasm-v1-semantic-gen.cpp.
